MacDon A40D - Lubrication Points: Drivelines

262334 139 Revision A
Lubrication Points: Drivelines
There are several points on the drivelines which will require lubrication.
NOTE:
High Temperature Extreme Pressure (EP2) Performance With 1% Max Molybdenum Disulphide (NLGI Grade 2) Lithium
Base. To prevent binding and/or excessive wear caused by knife pressing on guards, do NOT over-grease the lubrication
points. If more than 6 to 8 pumps of grease gun are required to fill the cavity, replace the seal in the knifehead.
Figure 4.12: Drivelines
1006108
A
B
B
C
C
D
D
D
A
B
B
B
A - Driveline Shafts (2 Places) (50 hours) - NOTE: 10% Moly Grease Is Recommended For Driveline Shaft Slip Joints ONLY.
B - Cross Shafts (2 Places) (50 Hours) C - Driveline Universals (2 Places) (50 Hours) D - Driveline Universals (2 Places) (50 Hours)
MAINTENANCE AND SERVICING
