MacDon A40D - Setting Float Options with Fixed Deck - M2 Series Windrowers

262334 93 Revision A
A
ϭϬϰϭϴϰϬ
Figure 3.136: HarvestTouch
™
Display
4. Press FLOAT SETTINGS icon (A) on the HarvestTouch
™
Display to show the float setting page.
ϭϬϰϮϬϯϯ
A
Figure 3.137: HarvestTouch
™
Display
5. Press float switch (A) on the FLOAT ADJUST page to remove
or restore the header float.
6. Shut down the engine, and remove the key from
the ignition.
Setting Float Options with Fixed Deck – M2 Series Windrowers
When using an auger header, the DECK SHIFT buttons can be used to store three float settings. This is useful when ground
conditions vary, or when having one side lighter is desirable (such as cutting along wheel tracks or irrigation borders).
DANGER
Ensure that all bystanders have cleared the area.
OPERATION
