MacDon A40D - Removing Forming Shield

262334 197 Revision A
1027351
A
Figure 4.132: Gearbox Breather
7. Add oil at (A) to the required level. Refer to the inside back
cover for the recommended lubricant.
1005801
B
Figure 4.133: Check Plug
NOTE:
The oil is at the required level when it runs out of check
plug (B).
4.14.2 Removing Forming Shield
Follow the provided procedure to remove the forming shield.
DANGER
To prevent injury or death from the unexpected start-up of the machine, always stop the engine and remove the key
from the ignition before leaving the operator’s seat for any reason.
1. Shut down the engine, and remove the key from the ignition.
MAINTENANCE AND SERVICING
