262334 196 Revision A
Figure 4.129: Gearbox Breather
Figure 4.130: Check Plug
4. Place a suitable container under the gearbox drain to
collect the oil.
5. Remove breather (A) and check plug (B).
Figure 4.131: Gearbox Drain
6. Remove drain plug (A) and allow the oil to drain. Replace
the drain plug once the oil has drained.
MAINTENANCE AND SERVICING
