5.1.3 Replacement Reel Bat Kit
This kit consists of one complete bat assembly for ease of replacement.
1005396
Figure 5.3: Reel Bat Assembly
Separate kits are available for different header widths:
• 4.3 m (14 ft.): B4716
• 4.9 m (16 ft.): B4717
• 5.5 m (18 ft.): B4718
5.1.4 Stub Guard Conversion Kit
Stub guards, complete with top guides and adjuster plates are designed to cut tough crops.
1001244
Figure 5.4: Stub Guards
Separate kits are available for different header widths:
• 4.3 m (14 ft.) Double-Knife: B4956
• 4.9 m (16 ft.) Double-Knife: B4715
• 5.5 m (18 ft.) Double-Knife: B4957
Installation and adjustment instructions are included with
the kit.
