MacDon A40D - Lubrication Points: Knife and Gearbox

262334 140 Revision A
Lubrication Points: Knife and Gearbox
There are several points on the knife and the gear which will require lubrication.
Refer to the following illustration to identify the various locations that require lubrication. Refer to the inside back cover of
this manual for proper oil recommendations.
1022228
A
B
C
C
Figure 4.13: Knife and Gearbox
A - Oil the Knife Daily Except in Sandy Soil (SAE 30) C - Knife Drive Box (2 Places)
3
B - Check the Roll Gearbox (1 Place)
4
MAINTENANCE AND SERVICING
3. Check oil level with the header down on level ground.
4. Header should be on the ground.
