MacDon A40D - Windrow Forming Rods

262334 117 Revision A
3.11.5 Windrow Forming Rods
The forming rods are provided to assist in forming the narrow windrows preferred for this application.
Bend the rods to modify the windrow shape. Use the forming rods in conjunction with the auger pan extensions to achieve
the width and the shape of the desired windrows.
Figure 3.171: Windrow Forming Rods
1005286
A
A
OPERATION
