Table 2.2 A40D and A40DX Auger Header Specifications (continued)
Delivery opening width
2430 mm (95 11/16 in.)
Reel
Oval closed section bats with end caps.
NOTE: Grass Seed Special model has standard seven-bat reel
6 bats
optional 7 bat
Steel fingers
6 mm (1/4 in.) diameter
Reel radius (to finger tip) 540 mm (22 in.)
Single piece tine bar with replaceable polyethylene bearings
N/A
Sectioned tine bar with regreasable ball bearings
Standard
Drive
Hydraulic motor: 14.2 cu in.
(232 cc) /rev to enclosed gearbox
Standard
Reel speed
M100/M105/M205 SP hydraulic variable
50–85 rpm
Reel speed
M150/M155/M155E4/M200 SP hydraulic
variable
15–85 rpm
Reel speed
M1170/M1240 and M2170/M2260 SP
hydraulic variable (with variable speed kit
installed)
15–85 rpm
Reel speed
M1170/M1240 and M2170/M2260 SP
hydraulic variable (standard reel)
50–85 rpm
Hay Conditioner
Roll-type Intermeshing steel bars
Roll size
Length
2590 mm (102 in.)
Roll size Overall
233 mm (9 3/16 in.)
Roll size
Tube
168 mm (6 5/8 in.)
Drive: 44 cc. hydraulic piston motor to enclosed gearbox
Standard
Roll speed SP windrower
601–810 rpm
Plug Prevention / Unplugging
Self-propelled
Reverse hydraulic flow to three motors
(reverses knife, auger, reel, and conditioner)
Optional
Swath Forming Shield
Swath width range
915 mm (36 in.) to
2540 mm (100 in.)
Header-mounted adjustable baffle
Standard
Attachment Windrower
Adjustable side deflectors
Standard
Frame And Structure
Two amber transport lights
Standard
Header width
Nominal cut width plus
480 mm (18 7/8 in.)
Header attachment
Windrower
Spare knife storage Lean bar
Tool and parts storage compartment
N/A
Header Hydraulics Connection
Direct coupled hoses
N/A
