262334 60 Revision A
1031267
A
B
C
D
Figure 3.71: Driveshield – Headers Sold outside North
America
3. Headers sold outside North America: Insert a tool into
hole (A) and pry to release latch (B). Disengage rubber
latch (C) and open driveshield (D).
1023843
Figure 3.72: Driveshield Open
The driveshield is shown in the open position.
OPERATION
