28 Manual control
900 Touch Control
￭￭￭￭￭￭￭￭
271
ease (see "Assigning lift positions", page 271). This definition is possible in
this dialog for the attached rack, and in the device manager for all of the
racks in the list.
Current lift pos.
Current lift position.
Move to lift pos.
Selecting a predefined lift position or enter any lift position.
Input range 0 to 'maximum stroke path' mm
A lift position of 0 mm corresponds to the "home
position", i.e. the lift is located at the upper stop
position. The maximum stroke path is defined in the
properties of the tower (see "Maximum stroke
path", page 94). If a higher value is entered, an
error message will be displayed.
Selection Work position | Shift position | Rinse position |
Special position
Default value Work position
Lift rate
Rate at which the lift is moved in the manual control.
Input range 5 to 25 mm/s
Default value 25 mm/s
[Assign lift pos.]
Assign the current lift position to a preset lift position.
Assigning lift positions
Specific lift positions are stored separately for every sample rack used as
well as for tower 1 and tower 2. The following specific lift positions are
available:
￭ General rack positions
For general rack positions you can define one work position, one shift
position and one rinse position as well as one special position.
￭ Special beaker positions
A specific work position can be defined for each special beaker. The
definitions of the general rack positions are used for the shift position,
rinse position and special position of the affected tower.
