Report Options Files ASAP 2460 Operator’s Manual
3-32 246-42800-01 - Aug 2013
Overlays button Refer to Multiple Sample Overlays, page 2-53.
Import button Use to import up to 25 pore distribution data files. These datasets are
shown only in BJH and Dollimore-Heal reports.
Apply thermal
transpiration
correction checkbox
Use to correct the temperature-induced pressure difference between the
manifold and the chilled sample tube. This option is most significant for
pressures less than approximately 1.0 mmHg. Do not use filler rods in the
sample tube when applying correction for thermal transpiration.
Always use thermal transpiration when performing micropore analyses.
Refer to CALCULATIONS, page C-1 for additional information on
thermal transpiration.
• Inside diameter of sample tube text box - Enabled when Apply
thermal transpiration correction is selected. Enter the inside
diameter of the sample tube used in the analysis.
Selected Reports list
box
Select the checkbox to the left of the report names to include in the report.
For BJH reports, BJH pore dimension can be calculated in pore width (w),
pore radius (R) or pore diameter (D). Go to Options > Units to specify
default calculations.
Browse button
Cancel button
Close button
Edit button
OK button
Preview button
Save button
Refer to Common Fields and Buttons - File Menu Options, page 3-1.
Field or Button Description (continued)
