Report Options Files ASAP 2460 Operator’s Manual
3-38 246-42800-01 - Aug 2013
BET (or Langmuir)
Transform plot
Use to generate a traditional BET (Langmuir) surface area plot used to
determine monolayer volume and BET C constant.
• Overlay samples checkbox - use to overlay sample files on the BET
(or Langmuir) transform plot.
• Autoscale x-axis - linear x-axes begin at zero. The x-axis field shows
the relative pressure for BET and show absolute pressure for Langmuir.
• Autoscale y-axis - the y-axis field shows BET (Langmuir)
transformation.
BET (or Langmuir)
Isotherm plot
Uses the BET (Langmuir) monolayer volume and constant to produce an
isotherm.
• Overlay samples checkbox - use to overlay sample files on the BET
(or Langmuir) isotherm plot.
• Autoscale x-axis - linear x-axes begin at zero. The x-axis field shows
the relative pressure for BET and show absolute pressure for Langmuir.
• Autoscale y-axis - the y-axis field shows the quantity of gas adsorbed.
Pressures button Refer to Pressures button, page 3-30.
Cancel button
Close button
From / To text boxes
OK button
Refer to Common Fields and Buttons - File Menu Options, page 3-1.
Field or Button Description (continued)
