Filling Dewars
ASAP 2460 Operator’s Manual
2-38
246-42800-01 - Aug 2013
6.
Attach the safety shield to the two hooks on the
front panel to enclose the sample tube and dewar
.
7.
Begin the analysis as described in the next topic.
67
69
