Description of Function Codes NICE1000
new
User Manual
- 150 -
5. Current position: indicates the absolute distance from the current elevator car to the
leveling plate of the rst oor, in unit of m.
6. Car load: indicates the percentage of the car load to the rated load judged by the
NICE1000
new
system based on data from the sensor, in unit of %.
7. Output voltage: indicates the effective value of the equivalent voltage of the PWM wave
output by the NICE1000
new
system, in unit of V.
8. Output current: indicates the effective value of the actual current when the NICE1000
new
system drives the motor to turn, in unit of A.
9. Output frequency: indicates the actual frequency of the motor during running. It has a
xed corresponding relationship with the running speed. The unit is Hz.
10. Pre-torque current: indicates the percentage of the pre-torque current compensated
during startup to the rated current, in unit of %.
11. Input terminal 1 state: indicate the meaning of input terminals by bit. "1" indicates that
the signal is active.
A total of 16 bits are dened as below:
Bit Meaning Bit Meaning
Bit0 Reserved Bit8 Shorting door lock circuit contactor feedback
Bit1 Up leveling signal Bit9 Inspection signal
Bit2 Down leveling signal Bit10 Inspection up signal
Bit3 Door zone signal Bit11 Inspection down signal
Bit4 RUN contactor feedback Bit12 Fire emergency signal
Bit5 Brake contactor feedback Bit13 Reserved
Bit6 Brake travel switch feedback Bit14 Elevator lock signal
Bit7 Self-lock feedback Bit15 Up limit signal
12. Input terminal 2 state: indicate the meaning of input terminals by bit. "1" indicates that
the signal is active.
A total of 16 bits are dened as below:
Bit Meaning Bit Meaning
Bit0 Down limit signal Bit8 Door 1 close limit
Bit1 Up slow-down signal Bit9 Door 2 close limit
Bit2 Down slow-down signal Bit10 Door machine 1 light curtain
Bit3 Overload signal Bit11 Door machine 2 light curtain
Bit4 Full-load signal Bit12 Attendant signal
Bit5 Emergency stop (safety feedback) signal Bit13 Direct travel ride signal
Bit6 Door 1 open limit Bit14 Direction change signal
Bit7 Door 2 open limit Bit15 Independent running
13. Input terminal 3 state: indicates the meaning of output terminals by bit. "1" indicates that
