- 189 -
Fault
Code
Name Possible Causes Solution Level
Err52
HCB
communication
abnormal
101: Feedback data of
Modbus communication
with the HCB remains
incorrect.
101:
•
Check the communication
cable connection.
•
Check whether the 24 V power
supply of the controller is
normal.
•
Check whether the HCB
addresses are repeated.
•
Check whether strong-power
interference on communication
exists.
1A
Err53 Door lock fault
101: The door lock
feedback signal remains
active for more than 3s
during door open.
102: The multiple door lock
feedback signal states are
inconsistent for more than
2s.
101:
•
Check whether the door lock
circuit is normal.
•
Check whether the feedback
contact of the door lock
contactor acts properly.
•
Check whether the system
receives the door open limit
signal when the door lock
signal is valid.
102:
Check whether when the hall
door lock signal and the car
door lock signal are detected
separately, the detected states of
the hall door locks and car door
lock are inconsistent.
5A
Err54
Overcurrent
at inspection
startup
The current at startup for
inspection exceeds 110% of
the rated current.
•
Reduce the load
•
Change Bit1 of FC-00 to 1
to cancel the startup current
detection function.
5A
Err55
Stop at another
landing oor
101: During automatic
running of the elevator,
the door open limit is not
achieved at the present
oor.
101: Check the door open limit
signal at the present oor.
1A
Err57
Serial
peripheral
interface (SPI)
communication
abnormal
101, 102: The SPI
communication is
abnormal. No correct data
is received with 2s of DSP
communication.
103: The MCB does not
match the AC drive.
101, 102: Check the wiring
between the control board and
the drive board.
103: Contact the agent or
Monarch.
5A
