Monarch NICE1000 User Manual

Function Code Table NICE1000
new
User Manual
- 84 -
Function
Code
Parameter Name Setting Range Default Unit
Property
F3-05 Deceleration rate 0.200–0.800 0.300 m/s2
★
F3-06
Deceleration end jerk
time
0.300–4.000 2.500 s
★
F3-07
Deceleration start jerk
time
0.300–4.000 2.500 s
★
F3-08
Special deceleration
rate
0.200–2.000 0.500 m/s2
★
F3-09
Pre-deceleration
distance
0–90.0 0.0 mm
★
F3-10 Re-leveling speed 0.000–0.080 0.040 m/s
★
F3-11 Inspection speed 0.100–0.500 0.250 m/s
★
F3-12
Position of up slow-
down
0.000–300.00 0.00 m
★
F3-13
Position of down slow-
down
0.000–300.00 0.00 m
★
F3-14
Zero-speed control
time at startup
0.000–1.000 0.200 s
★
F3-15 Brake release delay 0.000–2.000 0.600 s
★
F3-16
Zero-speed control
time at end
0.000–1.000 0.300 s
★
F3-17
Low-speed re-leveling
speed
0.080 to F3-11 0.100 m/s
★
F3-18
Acceleration rate at
emergency evacuation
0.100–1.300 0.300 m/s2
★
Group F4: Floor Parameters
F4-00 Leveling adjustment 0–60 30 mm
★
F4-01 Current oor F6-01 to F6-00 1 -
★
F4-02
High byte of current
oor position
0–65535 1 Pulses
●
F4-03
Low byte of current
oor position
0–65535 34464 Pulses
●
F4-04
Length 1 of leveling
plate
0–65535 0 Pulses
★
F4-05
Length 2 of leveling
plate
0–65535 0 Pulses
★
F4-06
High byte of oor
height 1
0–65535 0 Pulses
★
F4-07
Low byte of oor height
1
0–65535 0 Pulses
★
F4-08
High byte of oor
height 2
0–65535 0 Pulses
★
