Adjust Brake to 125% of Full Load
2-83
2
Motion 4000
Adjust Brake to 125% of Full Load
1. Bring the car to the bottom landing.
2. Place weights in the car to 2/3 of contract load.
3. Add an additional 50 or 100 pounds.
4. Move the car up a short distance on Inspection.
5. Run the car down and trip the stop switch.
6. Adjust the brake if it does not hold.
7. Repeat until the brake is holding 125% of full load capacity.
8. Remove test weights from car.
Caution
Keep the car near the bottom floor as it is likely to slide through the brake onto the buffers if
brake spring tension is inadequate.
Traction Auxiliary Power Supply
If you are installing the TAPS (Traction Auxiliary Power Supply) from MCE to provide emer-
gency power for passenger rescue in the event of commercial power loss, follow instructions in
the TAPS manual delivered with the unit.
If TAPS is used with the TorqMax/KEB F5 drive, drive parameter LF.61, Emergency Operation
Mode, must be set to di1. If not, the motor is not correctly powered during TAPS operation.
