F1: Program Mode
4-13
4
Motion 4000
Basic Features Menu
• CONTROLLER TYPE: TRACTION (M4000)
• Identifies controller type to the HC-CPU board.
• Set to TRACTION (M4000). This is the factory default.
When learning to set parameters, it is very easy to unintentionally set the Controller Type to
Motion 2000. If this occurs, you will see the error “MUSE INPUT IS LOW.” To correct, set the
Controller Type to M4000, press N repeatedly until the Save Changes menu appears, then press
S to save changes.
• SIMPLEX/LOCAL OR DUPLEX?
• Each controller is programmed at the factory for either simplex/local, or duplex opera-
tion. If the controller is a simplex, it assigns calls only for itself. The Duplex option will
not appear.
• If the controller is a duplex, it can operate a single car as a simplex or it can be con-
nected to a second Motion 4000 controller and the two can operate as a duplex.
•Both controllers must have duplex capability for duplexing to work. The option on
each controller must be set to duplex. Jumper JP3 on each HC-MPU (lower right cor-
ner) must be in place for successful Duplex operation.
• If the controller is controlled by a group dispatcher, it should be set to Simplex/Local.
In Duplex configuration, one of the controllers will assert itself as the dispatcher and will
remain the dispatcher unless it is taken offline. The dispatching controller will show a “D” on its
LCD; the other, an “S.” Hall calls are physically connected to both controllers.
•OPERATION:
• Dispatching operation - For simplex operation, you may choose: Selective Collective,
Single Button Collective, or Single Automatic Push button:
• Selective Collective - Use if there is an UP and DOWN button at each landing except for the
top floor (DOWN button only) and bottom floor (UP button only) and any number of hall
calls can be registered at one time.
• Single Button Collective - Use if there is only one call button at each landing and any num-
ber of calls can be registered at one time.
• Single Automatic Push button - Use if there is only one call button at each landing and only
one call can be registered and/or serviced at a time.
If Single Button Collective or Single Automatic Push button operation is selected, one of the
spare outputs should be used for an INDFRC output. This is used to disconnect hall calls during
Fire Service and Independent Service (see “Spare Outputs Menu” on page 4-35, INDFRC output
and your job prints for more detail). For duplex operation, the dispatching scheme is always
Selective Collective so the Operation option message will not appear if duplex is selected.
