Motion 4000
Door Operator and Door Peripherals
Check the job prints to see that the door operator you are installing is the operator shown in
your job prints.
• Install the operator according to manufacturer instructions.
• Make door operator electrical connections as shown in the MCE job prints.
• Verify that all door related switches and locks are properly installed, adjusted, and wired.
Door Safety Equipment
• Install photo eyes and/or safety edges in accordance with manufacturer instructions.
• Make connections to MCE control as shown in the job prints.
Door Switches
1. Install top, middle, and bottom door locks in accordance with drawings package.
2. Install gate switch and all car door position and limit switches.
Car Operating Panels, Position Indicators, and Peripherals
• Install operating panels according to manufacturer instructions.
• If the job uses the Motion 4000 serial control panel option, install Control Panel Interface
board(s) from MCE. Please refer to “ICE-COP-2 Car Panel Interface Board” on page 5-62
or MC-CPI Car Panel Interface Board on page 5-66.
• Make electrical connections as shown in the MCE job prints for all panel buttons and indi-
cators, position indicators, and controller-connected peripherals (fan/light timer, etc.).
• A special interface board, MC-ZXFIX, allows Kinetek/ZXK position indicators to be used
with MCE controllers. If used, connection instructions are provided in the prints for the
job.
Fire Service Peripherals
1. Refer to the MCE job prints.
2. Make electrical connections to fire service switches, sensors, indicators, and buzzers as
shown.
Note
After the car is adjusted and running on Automatic operation, fire recall, fire operation, and
proper fire or smoke sensors and indicators will be exercised for correct operation.
