Motion 4000 Traction Elevator Control
1-12 Manual # 42-02-2P24
Sabbath Operation
Sabbath operation is a special mode that sets the car to consecutively service specified landings
(and openings if the car has front and rear doors) during up and down travel with no hall or car
call buttons being pressed. The car will begin from the bottom of the hoistway, travelling up and
stopping at each designated stop and opening its doors to allow exit or entry. When the doors
close, the car will travel to the next designated stop up the hoistway and repeat door operation.
This will continue until the car reaches the top designated stop, at which point it will travel
down the hoistway operating in the same manner.
• Initiate: Sabbath operation is initiated when the spare input SAB is activated.
• Operation: In accordance with the description above and servicing stops set through the
Sabbath Operation parameter in the Extra Features menu. Please refer to “Extra Features
Menu Options” on page 4-42.
Emergency Medical Operation
This mode complies to Massachusetts code. It allows a car to be recalled to a floor where it can
be boarded by medical personnel and placed in restricted service, using an in-car switch, to
respond to a medical emergency.
• Recall: Initiated using a key switch (EMSH input) at the floor assigned by the Massachu-
setts EMS Service/EMS Service Floor parameter in the Extra Features menu (single
switch, single floor).
• The car will immediately cancel all registered calls, return to the designated floor, and
open its doors.
• In-Car Medical: Medical personnel board the car and place it in hospital service using the
in-car switch (EMSC input).
• If the hall switch has been shut off, the car will wait sixty seconds then return to nor-
mal service if the in-car switch has not been activated.
• If the hall switch remains on, the car will wait without restriction until the in-car
switch is activated.
