Motion Control Engineering Motion 4000 User Manual

4-1
In this Section
The default user interface to the Motion 4000 Traction Control is the LCD and keypad on the
HC-MPU board. A hand-held user interface that functions like the LCD and keypad may also be
provided. The hand-held user interface provides access when plugged into any CAN Bus con-
nector in the system. This section describes user interface functionality:
• HC-MPU Main Processor: Board indicators, switches, buttons, connectors and display
• Access Security: Optional password protection system (see page 4-5).
Adjustments to system settings are made using switches and buttons on the MPU board or on
the hand-held control. There are eight different “functions,” each of which accesses different
groups of settings. On the MPU board, you access a functional area by moving one of eight
“function” switches to the UP position. On the hand-held, you press a “function” button.
• With no function selected: Diagnostic messages are displayed. See page 4-6.
•F1 — Program Mode:
• Basic Features Menu (see page 4-13)
• Fire Service Menu (see page 4-16)
• Door Operation Menu (see page 4-18)
• Timer Menu (see page 4-23)
• Gongs/Lanterns Menu (see page 4-25)
• Spare Inputs Menu (see page 4-26)
• Spare Outputs Menu (see page 4-35)
• Extra Features Menu (see page 4-42)
• Additional Car Options (see page 4-49)
User Interface
