F1: Program Mode
4-25
4
Motion 4000
Gongs/Lanterns Menu
• MOUNTED IN HALL OR CAR?
• Determines when lanterns and gongs are activated - as the car slows into the floor for
hall mounted fixtures or after the door lock opens for car mounted fixtures. If both
types of lanterns are used, the Hall option is recommended.
• DOUBLE STRIKE ON DOWN?
• Causes lanterns and gongs to double-strike if car direction preference is down.
• PFG ENABLE BUTTON? (Passing Floor Gong Enable Button)
• If selected, the Passing Floor Gong will operate only when initiated by a momentary
pressure button. Once initiated, the Passing Floor Gong will operate for the current
direction of travel but will be rendered inoperative when the car reverses direction.
The PFGE spare input should also be selected if this option is turned ON. (See “Spare
Inputs Menu” on page 4-26.)
• EGRESS FLOOR ARRIVAL GONG? / MAIN EGRESS FLOOR #
• To program this option (Michigan Code), set one of the spare outputs to EFG. Then set
EGRESS FLOOR ARRIVAL GONG? to NO (no gong) or press S to select the floor num-
ber where the gong should activate (after the door lock opens). If S is pressed, the dis-
play will read MAIN EGRESS FLOOR #1. Press S until the desired floor number is
displayed.
• CAR LANTERN DOOR FULLY OPEN?
• If no, the car lantern will come on when the doors begin to open and go off when they
are fully closed. If yes, the car lantern will come when the doors are fully open and go
off when they begin to close.
