Installation
2-48 Manual # 42-02-2P24
HPV 900PM
1. Place the controller on Inspection.
2. Set controller F7, 141, Profile Scale to 0.0%.
3. In the controller F3, Controller Utilities menu, set Inspection Mode Fault Bypass to ON.
(Jumper must be in place on HC-CTL board Fault Reset Jumper J1.)
4. Disable the machine brake. (Remove brake wire from brake coil if discrete brake circuit
is being used or set the Normal Brake Pick/Hold Voltage (F7, 194 and 195) to 0.0 if a
brake module is being used.)
5. Refer to and follow the Absolute Encoder Alignment, Alignment Via Car Controller pro-
cedure in the Magnetek HPV 900PM AC Drive technical manual.
6. Restore controller to original settings.
Brake Basics
1. Ensure that the brake is picking cleanly. With the car set up so that it will not move:
• Manually activate the PM and BR contactors to lift the brake.
• Measure DC voltage between terminals B1 and B2. It should be very close to the pick
voltage shown in your job prints.
• Refer to job prints and adjust pick voltage if necessary.
2. Ensure that, when set, the brake is capable of holding 125% of rated car capacity. Refer
to Adjust Brake to 125% of Full Load on page 2-83.
3. Check that brake and motor coordination are such that the brake is dropping just when
motor rotation stops.
4. Check that the brake pick delay allows the motor to build sufficient flux to prevent roll
back when the car is starting.
