F1: Program Mode
4-11
4
Motion 4000
F1: Program Mode
These parameters define the building, floors and openings to be served, and other basic require-
ments for the elevator.
Put the car on Inspection and set Function switch F1 up (all others
down) to enter Program mode.
Refer to the Programming Record in the Job Prints for a list of the
options and values programmed into the controller at MCE.
If you make programming changes, record them in the reference table, Appendix A, page A-21.
General Description of Program Mode
Programmable options and features are divided among several menus:
Basic Features Menu Timer Menu Spare Outputs Menu
Fire Service Menu Gongs/Lanterns Menu Extra Features Menu
Door Operation Menu Spare Inputs Menu Additional Car Options Menu
Changing Parameters
Enter Program mode. The Start Message will appear:
• Press N to cycle through the menus.
• Press S when the menu you want appears.
• Press N to view the first option in the menu. (Press
repeatedly or hold down to cycle through options.)
• Press S to change the value (i.e., from YES to NO).
Saving Changes
After selecting the new value:
• Press N until the save message appears:
• Press S to save changes (or N if you want to cancel the
change).
Unsaved changes will
be LOST when the F1
switch is placed in the
down position (exiting
Program mode).
Be sure to enter
changed parameter
values in the table pro-
vided in Appendix A.
