Installation
2-84 Manual # 42-02-2P24
Installation Review
• Carefully review MCE job prints and job requirements.
• Ensure that all equipment has been correctly installed and connected.
• Verify that all jumpers placed during installation have been removed and replaced with
permanent connections.
• Verify that all safety equipment is installed and is functioning properly.
• Ensure that Inspection faults are no longer on bypass in the Controller System Menu (F3
function switch on MPU board)
At this point, controller and related installation should be complete. The car should be running
safely on Inspection operation from the cartop and/or the machine room. The next section will
describe:
• Learning the hoistway
• Setting controller parameters
• Setting drive parameters
•Performance Adjustment
• Final Test
