Set Up for Construction Operation
2-31
2
Motion 4000
Required Drive Parameter Settings
In order to operate safely in construction, particular drive parameters must be verified and set.
These parameters are set at the factory according to your job requirements but MUST BE
CHECKED for correctness BEFORE PROCEEDING.
Before powering the controller to make these settings, verify that the Inspection/Normal
switch is in the Inspection position.
Torqmax F5 AC Drive Parameters
Set drive parameters using the drive keypad. If drive parameters are not correctly set, attempt-
ing to move the elevator can be VERY DANGEROUS. MCE sets these parameters before ship-
ment, but you must check them at the site.
Drive parameters must be correctly set. If not, elevator control can be erratic and potentially
DANGEROUS. Never change drive parameters while the elevator is running.
1. Read the drive manufacturer manual shipped with this controller. It provides essential
information about setting up the drive that cannot be included in the MCE manual. Fol-
low the Initial Start-up procedure described in the drive manufacturer manual.
2. Read and follow the parameter settings in the table shipped with the controller from
MCE.
The following drive parameter table is included for your convenience and in the event the table
shipped with the controller is not available. Note that the table here reflects generic settings, not
those specific to your installation. In the table, IM= induction motor; PM= permanent magnet
motor.
Table 2.3 Critical F5 Drive Parameters
Parameter Parameter
LF.02 Operating mode: SErSP LF.21 Traction sheave diameter
LF.04 Per Motor LF.22 Gear reduction ratio
LF.10 Rated motor power (HP) LF.23 Roping ratio
LF.11 Rated motor speed LF.24 Load weight
LF.12 Rated motor current LF.27 Encoder pulses
LF.13 Rated motor frequency LF.30 Closed Loop: 2
LF.14 Rated motor voltage d.LF.33 Ki speed offset decel
LF.17 Rated motor torque US.35 Reference splitting: 40
LF.20 Contract speed
