Motion Control Engineering Motion 4000 User Manual

Installation
2-32 Manual # 42-02-2P24
Table 2.4 TorqMax F5 Parameters
Display Parameter Description Unit Range Default Factory
WARNING: Do not change drive parameters while the elevator is running. Incorrect drive
parameter values can cause erratic operation.
WARNING: Parameters with an asterisk (*) must be set correctly for your specific motor /
machine / job. Refer to the adjustment manual for detailed information.
LF. 2 Signal operating mode:
AbSPd - Absolute Analog Speed
d SPd - Digital Speed Selection
A tor - Analog Torque Control
A Spd - Analog Speed Control
SerSP - Serial Com. Speed Control
bnSPd - Binary Speed Selection
S POS – Serial Position feedback
-AbSPd
d Spd
A tor
A Spd
SerSP
BnSPd
S POS
bnSPd SerSP
LF. 3 Drive configuration:
run- run mode
conF - Configuration (5 minute time limit)
Stop - Drive stopped, Motor cannot run. Drive
will not respond. When using serial com,
this mode allows parameter changes
S Lrn - activate auto tune
I Lrn - Inertia Learn. Learns the system inertia
and activates the FFTC.
P Lrn: Pole Learn. Learn the pole positions of
PM Motor
SPI - Stationary Pole Learn. Learn absolute
encoder position for PM machine under
brake without sheave movement.
(N/A for software Version 1.61)
OStST - Over speed test function. Allows car to
over speed machine to test governor.
(N/A for software Version 1.61)
-run
conF
Stop
S Lrn
I Lrn
P Lrn
SPI
OStST
conF run
LF. 4 Motor-selection: Displays mode selected using US.
4 and US.10
ICLSd - Close loop induction
I9LSS = Closed loop induction gearless
PCLSd = Closed loop permanent magnet (PM)
P9LSS = Closed loop PM gearless
- see US.10 - ***
LF. 5 Drive fault auto reset 1 0 - 10 5 5
LF. 8 Electronic motor overload protection - on, off off on
LF. 9 IM - Electronic overload current
PM - not visible, auto set same as LF.12
A 1.0 - 110%
Drive rated
8.0 *
LF.10 IM - Rated motor power
PM - read only, auto calc.
HP 0.00 - 125.00 5.00 *
LF.11 Rated motor speed rpm 10.0 - 6000.0 1165 or
150
*
LF.12 Rated motor current A 1.0 - 110%
Drive rated
8.0 *
LF.13 Rated motor frequency Hz 4.0 - 100.0 60.0 *
LF.14 Rated motor voltage
IM - Name plate rated voltage
PM - No-load, phase-to-phase back EMF rms volt-
age at LF.11
V IM: 120 - 500V
PM: 1 -
32000V/krpm
230/460 *
