Final Tests
3-51
3
Motion 4000
195
Normal Brake Hold Volt-
age
0V 300V
196
Normal Brake Relevel
Voltage
0V 300V
197 Normal Brake Lift Rate 0% 100%
198
Normal Brake Drop
Rate
0% 100%
199 Emergency Brake Type Module or Discrete
200
Emergency Brake Pick
Voltage
0V 300V
201
Emergency Brake Hold
Voltage
0V 300V
202 Directional Limit Type Virtual Virtual or Physical
203
Landing System Floor
Checksum
This is a read only value. When the hoistway is learned with the LS-EDGE
landing system, the learned parameters are stored in the landing system sen-
sor and this checksum is both stored in the sensor and sent to the controller.
If the controller should read a different checksum (i.e., if the sensor head is
changed), a new hoistway learn must be performed.
204
Landing System ETS
Overspeed
0% 10% 100%
Used to set the LS-EDGE landing
system hardware ETS overspeed
threshold as a percentage of
contract speed. Magnets on the
landing system tape (one lane
for UETS and another for DETS)
are monitored by the LS-EDGE,
detecting the speed at which the
car passes. The controller still
allows a virtual/physical ETS
switch in addition to the mag-
nets.
205 Inspection Slew filter +0.1 Hz +20.0 Hz +20 Hz
206 Battery Backup Speed 9 FPM 250 FPM 250 FPM
Table 3.4 F7 Parameters
# Item Min Default Max Notes
