F1: Program Mode
4-15
4
Motion 4000
•ALT. PARKING FLOOR
• Available only when an API input is programmed and a parking floor is set. Any land-
ing can be chosen as the alternate parking floor. The car will go to the alternate parking
floor when it is free of call demand and the API input is active.
• SECONDARY PARKING FLOOR
• Does not apply to Simplex. Any landing may be the secondary parking floor. A car will
go to this floor when it is free of call demand and the other car is already parked at the
first parking floor. It is acceptable to make the secondary parking floor the same as the
first parking floor if both cars are to park at the same floor. If a second parking floor is
not needed, choose NONE for the Secondary Park Floor option. The first free car will
go to the first parking floor and the second car will stay at the last call answered.
•LOBBY FLOOR
• Any landing may be the Lobby Floor. When the car answers a hall or car call at this
floor, the doors will stay open until the Lobby Door Timer elapses. The Lobby Door
Timer is adjustable (see “LOBBY DOOR TIMER (Range: 0.5-120.0 Seconds)” on
page 4-23). NOTE: The Lobby Floor is also used for the CTL (Car To Lobby) input.
• CAR IDENTIFIER
• Does not apply to Simplex. Specifies which controller is assigned to car A and which to
car B, primarily for controllers using a peripheral device such as a monitoring system.
Settings that affect the number of floors in the building, openings served per floor, discrete
or serial (CE) position indicators, or the presence or absence of a serial car call board deter-
mine the sequence of connections on Universal I/O boards used as “call boards” in the con-
troller (UIO boards with addresses from 0 to 31). These settings are made at the factory and
should never need to be changed. If you do need to change these settings, disconnect the
orange I/O terminal blocks from the UIO boards first, change the settings, then re-wire and
re-connect the terminal blocks.
• SERIAL COP BOARD TYPE?
• Set to type of installed serial COP board (MC-CPI, ICE-COP-2, or NONE. See caution
above.
• DISCRETE PI’s on UIO?
• Set to No if the car uses serial (CE) position indicator fixtures. See caution above.
• Set to Yes if PI’s are connected to HC-UIO boards.
• DEDICATED PI BOARD? (Appears if “Discrete PI’s on UIO?” is set to Yes. Dedicates first
one or two HC-UIO boards to PI’s alone [no call connections]).
• If Yes: Position Indicators will be located on UIO Board 0 (zero) for 2 - 16 stops or
boards 0 (zero) and 1 (one) for 2 - 32 stops (board 1 handles 17 - 32 [assuming that PI
is one wire per floor]). Calls will begin on a new UIO Board immediately following
Board 0 or 1.
• If No: PI’s are located on UIO boards but calls can begin immediately following the last
PI rather than on the next UIO board.
