F1: Program Mode
4-37
4
Motion 4000
CR01R-CR8R Car Card Reader Outputs, rear landings. Indicates the associated card reader input has
been activated (allowing car call registration to this rear landing). Once the call is regis-
tered, output will remain active until call completed.
CSB Car Stop Switch Bypass Output - Used to provide redundancy for the in-car stop switch
function. Activated during Fire Service Phase I to bypass the in-car stop switch (a similar
output is one of the standard outputs). With this second output, failure of one of these
devices (stuck in the active mode) will not cause the Stop switch to be bypassed improp-
erly. Redundancy is required by CSA.
CSEO Code Sequence Enable Output - Active when car is on security and ready to accept the
security code. Goes off once the code is accepted or the code entry timer elapses.
CSR Car Selected to Run Output - Generated when the car is selected to run on Emergency
Power phase 2 via the AUTO or EPRUN input.
CTLDOT Car-to-Lobby Door Open Timer Output - Generated upon completion of the car to lobby
function (the car has returned to the lobby landing, the doors have opened, and the CTL
door timer has expired).
DBZF Front Door Buzzer - Active prior to automatic closing of the front doors for the length of
time determined by the Door Buzzer Timer.
DBZR Rear Door Buzzer - Active prior to automatic closing of the rear doors for the length of time
determined by the Door Buzzer Timer.
DCFRX Like DCFX but for rear doors.
DCFX Door Close Function Auxiliary. Signals the controller to attempt to close the doors. Unlike
the standard DCF output on the HC-CTL board, this one is disabled on inspection, Fire
phase I, or Fire phase II operation.
DCPRX Like DCPX but for rear doors.
DCPX Door Close Power Auxiliary. Unlike the standard DCP output on the HC-CTL board, this one
is disabled on inspection, Fire phase I, or Fire phase II operation.
DHEND Door Hold End Output - Activates five seconds prior to Door Hold Timer expiration.
DHENDR Door Hold End Output Rear - Activates five seconds prior to Rear Door Hold Timer expira-
tion.
DHO Door Hold Output - Indicates doors are being held open by the door hold input function.
(The DHLDI input is active or the timer associated with the door hold function has not yet
elapsed.)
DISB Distress Buzzer. Activated when the emergency stop switch is pulled or the alarm bell input
(ABI) is activated. Pulsates if the SAFH, SAFC, or GOV inputs are low or if the TDISL output
is used.
DISL Distress Light. Activated when the car establishes an extended safety string fault or if the
emergency stop switch is pulled or the alarm bell input (ABI) activated.
DISLX Distress Light Auxiliary. Activated when the car is shut down due to a fault or the MGS or
PTI inputs are activated while a car call is latched.
DLOB Door Left Open Bell Output - Comes on when a call button is pressed and the door has
been left open. Used on single button collective and single automatic push button when the
hall and car call buttons are connected.
DNO Down output (Attendant Service) - Used on Attendant Service to indicate that a hall call
has been registered below the car and the car has been assigned to answer it. Normally
used to light an indicator to alert the attendant that such hall calls exist.
DNS Down Sense. Active while the car travels in the down direction.
DO1 DO2, DO4, DO8, DO16, D032 - Binary coded P.I. outputs for digital P.I. devices.
DOFRX Like DOFX but for rear doors.
DOFX
Door Open Function Auxiliary. Signals the door operator to attempt to open the doors.
Unlike the standard DOF output on the HC-CTL board, this one is disabled on inspection,
Fire phase I, or Fire phase II operation.
Table 4.7 Spare Outputs Menu Options
Spare Outputs Menu Options
