F2: External Memory Mode
4-51
4
Motion 4000
Table 4.8 Computer External Memory Chart
HALL CALLS CAR CALLS
ADD 876543 21
0140: 601R/UC1R 601/UC1 101R/CC1R 101/CC1
0141: 602R/UC2R 602/UC2 502R/DC2R 502/DC2 102R/CC2R 102/CC2
0142: 603R/UC3R 603/UC3 503R/DC3R 503/DC3 103R/CC3R 103/CC3
0143: 604R/UC4R 604/UC4 504R/DC4R 504/DC4 104R/CC4R 104/CC4
0144: 605R/UC5R 605/UC5 505R/DC5R 505/DC5 105R/CC5R 105/CC5
0145: 606R/UC6R 606/UC6 506R/DC6R 506/DC6 106R/CC6R 106/CC6
0146: 607R/UC7R 607/UC7 507R/DC7R 507/DC7 107R/CC7R 107/CC7
0147: 608R/UC8R 608/UC8 508R/DC8R 508/DC8 108R/CC8R 108/CC8
0148: 609R/UC9R 609/UC9 509R/DC9R 509/DC9 109R/CC9R 109/CC9
0149: 610R/UC10R 610/UC10 510R/DC10R 510/DC10 110R/CC10R 110/CC10
014A: 611R/UC11R 611/UC11 511R/DC11R 511/DC11 111R/CC11R 111/CC11
014B: 612R/UC12R 612/UC12 512R/DC12R 512/DC12 112R/CC12R 112/CC12
014C: 613R/UC13R 613/UC13 513R/DC13R 513/DC13 113R/CC13R 113/CC13
014D: 614R/UC14R 614/UC14 514R/DC14R 514/DC14 114R/CC14R 114/CC14
014E: 615R/UC15R 615/UC15 515R/DC15R 515/DC15 115R/CC15R 115/CC15
014F: 616R/UC16R 616/UC16 516R/DC16R 516/DC16 116R/CC16R 116/CC16
0150: 617R/UC17R 617/UC17 517R/DC17R 517/DC17 117R/CC17R 117/CC17
0151: 618R/UC18R 618/UC18 518R/DC18R 518/DC18 118R/CC18R 118/CC18
0152: 619R/UC19R 619/UC19 519R/DC19R 519/DC19 119R/CC19R 119/CC19
0153: 620R/UC20R 620/UC20 520R/DC20R 520/DC20 120R/CC20R 120//CC20
0154: 621R/UC21R 621/UC21 521R/DC21R 521/DC21 121R/CC21R 121/CC21
0155: 622R/UC22R 622/UC22 522R/DC22R 522/DC22 122R/CC22R 122/CC22
0156: 623R/UC23R 623/UC23 523R/DC23R 523/DC23 123R/CC23R 123/CC23
0157: 624R/UC24R 624/UC24 524R/DC24R 524/DC24 124R/CC24R 124/CC24
0158: 625R/UC25R 625/UC25 525R/DC25R 525/DC25 125R/CC25R 125/CC25
0159: 626R/UC26R 626/UC26 526R/DC26R 526/DC26 126R/CC26R 126/CC26
015A: 627R/UC27R 627/UC27 527R/DC27R 527/DC27 127R/CC27R 127/CC27
015B: 628R/UC28R 628/UC28 528R/DC28R 528DC28 128R/CC28R 128/CC28
015C: 629R/UC29R 629/UC29 529R/DC29R 529/DC29 129R/CC29R 129/CC29
015D: 630R/UC30R 630/UC30 530R/DC30R 530/DC30 130R/CC30R 130/CC30
015E: 631R/UC31R 631/UC31 531R/DC31R 531/DC31 131R/CC31R 131/CC31
015F: 532R/DC32R 532/DC32 132R/CC32R 132/CC32
SPARE INPUTS*
ADD 876543 21
02AF: SP8 SP7 SP6 SP5 SP4 SP3 SP2 SP1
02B0: SP16 SP15 SP14 SP13 SP12 SP11 SP10 SP9
02B1 SP24 SP23 SP22 SP21 SP20 SP19 SP18 SP17
02B2 SP32 SP31 SP30 SP29 SP28 SP27 SP26 SP25
02B3 SP40 SP39 SP38 SP37 SP36 SP35 SP34 SP33
02B4 SP48 SP47 SP46 SP45 SP44 SP43 SP42 SP41
02B5 SP50 SP49
* The first 10 spare inputs are located on the HC-CTL board. The remaining spare inputs are located on
HC-UIO boards numbered 32 through 36 (8 per board).
SPARE OUTPUTS **
ADD 876543 21
02EF: OUT4 OUT3 OUT2 OUT1
02F0: OUT12 OUT1 OUT10 OUT9 OUT8 OUT7 OUT6 OUT5
02F1: OUT20 OUT19 OUT18 OUT17 OUT16 OUT15 OUT14 OUT13
02F2: OUT28 OUT27 OUT26 OUT25 OUT24 OUT23 OUT22 OUT21
02F3: OUT36 OUT35 OUT34 OUT33 OUT32 OUT31 OUT30 OUT29
02F4: OUT44 OUT43 OUT44 OUT45 OUT46 OUT47 OUT48 OUT49
** The first four spare outputs are located on the HC-CTL board. The remaining spare outputs are located
on HC-UIO boards numbered 32 through 35 (8 per board).
