Motion Control Engineering Motion 4000 User Manual

F5 Menus
4-69
4
Motion 4000
82 Fault runs
83 Floor zone
84 Position bypass count
85 Position pass count
86 System position count
87 Absolute position count
88 Position lower sequence
89 Position upper sequence
90 Position lower value
91 Position upper value
92 Landing code
93 At landing
95 Near floor
100 Port A inputs: (n/a)
101
Port B inputs:
01 = TPM
02 = TBR
03 = PMP
04 = BRP
05 = UETS
06 = DETS
07 = SPI1
08 = SPI2
09 = EGOK
10 = RGR1
11 = RGR2
12 = RGOK
13 = EBPS
14 = EB RST
15 = SPI3
16 = SPI4
102
Port C inputs:
01 = PMDD
02 = (n/a)
03 = (n/a)
04 = (n/a)
05 = (n/a)
06 = (n/a)
07 = (n/a)
08 = (n/a)
09 = (n/a)
10 = (n/a)
11 = (n/a)
12 = (n/a)
13 = (n/a)
14 = (n/a)
15 = (n/a)
16 = (n/a)
103 Port D inputs: (n/a)
Table 4.12 MPI-A Diagnostics
Address Item Notes
