4-94 Manual # 42-02-2P24
61 Measured magnet length in counts
62 Floor height in counts
63 DLM edge in counts
64 ULM_edge in counts
70 Front Floor 7 Floor height (inch or mm)
71 Measured magnet length in counts
72 Floor height in counts
73 DLM edge in counts
74 ULM_edge in counts
80 Front Floor 8 Floor height (inch or mm)
81 Measured magnet length in counts
82 Floor height in counts
83 DLM edge in counts
84 ULM_edge in counts
90 Front Floor 9 Floor height (inch or mm)
91 Measured magnet length in counts
92 Floor height in counts
93 DLM edge in counts
94 ULM_edge in counts
100 Front Floor 10 Floor height (inch or mm)
101 Measured magnet length in counts
102 Floor height in counts
103 DLM edge in counts
104 ULM_edge in counts
110 Front Floor 11 Floor height (inch or mm)
111 Measured magnet length in counts
112 Floor height in counts
113 DLM edge in counts
114 ULM_edge in counts
120 Front Floor 12 Floor height (inch or mm)
121 Measured magnet length in counts
122 Floor height in counts
123 DLM edge in counts
124 ULM_edge in counts
130 Front Floor 13 Floor height (inch or mm)
131 Measured magnet length in counts
Table 4.15 LS-EDGE Diagnostics
Address Floor number Diagnostic
