User Interface
4-96 Manual # 42-02-2P24
203 DLM edge in counts
204 ULM_edge in counts
210 Front Floor 21 Floor height (inch or mm)
211 Measured magnet length in counts
212 Floor height in counts
213 DLM edge in counts
214 ULM_edge in counts
220 Front Floor 22 Floor height (inch or mm)
221 Measured magnet length in counts
222 Floor height in counts
223 DLM edge in counts
224 ULM_edge in counts
230 Front Floor 23 Floor height (inch or mm)
231 Measured magnet length in counts
232 Floor height in counts
233 DLM edge in counts
234 ULM_edge in counts
240 Front Floor 24 Floor height (inch or mm)
241 Measured magnet length in counts
242 Floor height in counts
243 DLM edge in counts
244 ULM_edge in counts
250 Front Floor 25 Floor height (inch or mm)
251 Measured magnet length in counts
252 Floor height in counts
253 DLM edge in counts
254 ULM_edge in counts
260 Front Floor 26 Floor height (inch or mm)
261 Measured magnet length in counts
262 Floor height in counts
263 DLM edge in counts
264 ULM_edge in counts
270 Front Floor 27 Floor height (inch or mm)
271 Measured magnet length in counts
272 Floor height in counts
273 DLM edge in counts
Table 4.15 LS-EDGE Diagnostics
