User Interface
4-102 Manual # 42-02-2P24
633 DLM edge in counts
634 ULM_edge in counts
640 Front Floor 64 Floor height (inch or mm)
641 Measured magnet length in counts
642 Floor height in counts
643 DLM edge in counts
644 ULM_edge in counts
650 Rear Floor 1 Floor height (inch or mm)
651 Measured magnet length in counts
652 Floor height in counts
653 DLM edge in counts
654 ULM_edge in counts
660 Rear Floor 2 Floor height (inch or mm)
661 Measured magnet length in counts
662 Floor height in counts
663 DLM edge in counts
664 ULM_edge in counts
670 Rear Floor 3 Floor height (inch or mm)
671 Measured magnet length in counts
672 Floor height in counts
673 DLM edge in counts
674 ULM_edge in counts
680 Rear Floor 4 Floor height (inch or mm)
681 Measured magnet length in counts
682 Floor height in counts
683 DLM edge in counts
684 ULM_edge in counts
690 Rear Floor 5 Floor height (inch or mm)
691 Measured magnet length in counts
692 Floor height in counts
693 DLM edge in counts
694 ULM_edge in counts
700 Rear Floor 6 Floor height (inch or mm)
701 Measured magnet length in counts
702 Floor height in counts
703 DLM edge in counts
Table 4.15 LS-EDGE Diagnostics
Address Floor number Diagnostic
