Motion Control Engineering Motion 4000 User Manual

F5 Menus
4-109
4
Motion 4000
1134 ULM_edge in counts
1140 Rear Floor 50 Floor height (inch or mm)
1141 Measured magnet length in counts
1142 Floor height in counts
1143 DLM edge in counts
1144 ULM_edge in counts
1150 Rear Floor 51 Floor height (inch or mm)
1151 Measured magnet length in counts
1152 Floor height in counts
1153 DLM edge in counts
1154 ULM_edge in counts
1160 Rear Floor 52 Floor height (inch or mm)
1161 Measured magnet length in counts
1162 Floor height in counts
1163 DLM edge in counts
1164 ULM_edge in counts
1170 Rear Floor 53 Floor height (inch or mm)
1171 Measured magnet length in counts
1172 Floor height in counts
1173 DLM edge in counts
1174 ULM_edge in counts
1180 Rear Floor 54 Floor height (inch or mm)
1181 Measured magnet length in counts
1182 Floor height in counts
1183 DLM edge in counts
1184 ULM_edge in counts
1190 Rear Floor 55 Floor height (inch or mm)
1191 Measured magnet length in counts
1192 Floor height in counts
1193 DLM edge in counts
1194 ULM_edge in counts
1200 Rear Floor 56 Floor height (inch or mm)
1201 Measured magnet length in counts
1202 Floor height in counts
1203 DLM edge in counts
1204 ULM_edge in counts
Table 4.15 LS-EDGE Diagnostics
Address Floor number Diagnostic
