KEB F5 Parameters Table
Enter the settings you make while adjusting into the Field column of the following table.
Table A.1 TorqMax F5 Parameters for Motion 4000
Display Parameter Description Unit Range Default Field
WARNING: Do not change drive parameters while the elevator is running. Incorrect drive
parameter values can cause erratic operation.
WARNING: Parameters with an asterisk (*) must be set correctly for your specific motor /
machine / job. Refer to the adjustment manual for detailed information.
LF. 2 Signal operating mode:
AbSPd - Absolute Analog Speed
d SPd - Digital Speed Selection
A tor - Analog Torque Control
A Spd - Analog Speed Control
SerSP - Serial Com. Speed Control
bnSPd - Binary Speed Selection
S POS – Serial Position feedback
-AbSPd
d Spd
A tor
A Spd
SerSP
BnSPd
S POS
bnSPd SerSP
LF. 3 Drive configuration:
run- run mode
conF - Configuration (5 minute time limit)
Stop - Drive stopped, Motor cannot run. Drive
will not respond. When using serial com,
this mode allows parameter changes
S Lrn - activate auto tune
I Lrn - Inertia Learn. Learns the system inertia
and activates the FFTC.
P Lrn: Pole Learn. Learn the pole positions of
PM Motor
SPI - Stationary Pole Learn. Learn absolute
encoder position for PM machine under
brake without sheave movement.
(N/A for software Version 1.61)
OStST - Over speed test function. Allows car to
over speed machine to test governor.
(N/A for software Version 1.61)
-run
conF
Stop
S Lrn
I Lrn
P Lrn
SPI
OStST
conF run
LF. 4 Motor-selection: Displays mode selected using US.
4 and US.10
ICLSd - Close loop induction
I9LSS = Closed loop induction gearless
PCLSd = Closed loop permanent magnet (PM)
P9LSS = Closed loop PM gearless
- see US.10 -
LF. 5 Drive fault auto reset 1 0 - 10 5
LF. 8 Electronic motor overload protection - on, off off
LF. 9 IM - Electronic overload current
PM - not visible, auto set same as LF.12
A 1.0 - 110%
Drive rated
8.0
LF.10 IM - Rated motor power
PM - read only, auto calc.
HP 0.00 - 125.00 5.00
LF.11 Rated motor speed rpm 10.0 - 6000.0 1165 or
150
LF.12 Rated motor current A 1.0 - 110%
Drive rated
8.0
LF.13 Rated motor frequency Hz 4.0 - 100.0 60.0
