Changing Conveyor Stacker
Positions
8.15
The Conveyor Stacker can be installed in three different positions:
•
In line (0 degrees)
•
At +90 degrees
•
At -90 degrees.
The installation at -90 degrees will be done by the technician who
will have to set the corresponding conveying speed and the direction
of the Conveyor.
How to Install the Conveyor Stacker in Line (0°)
Assembly of the Connection Plate
1. Align the flange of the two guide holes as shown by the arrow.
2. Attach the two feet of the Base in the two holes of the Connection Plate B .
222
| Page 222 | | janv.-12-2012 11:42 |
8
Configuring your Mailing System
