General Device Settings and Actions MDM6000 Satellite Modem
12.13.3 Encapsulator Configuration
Configure the encapsulator parameters that is used to set up the control plane.
Parameter Value Description
Nominal S2
ModCod
S2 ModCod
Range
Enter a S2 ModCod that is defined by the
weakest link of the setup. do this to make sure
that the signaling is transmitted under all
conditions.
Nominal S2 Ext
ModCod
S2 Ext ModCod
Range
Enter a S2 Ext ModCod that is defined by the
weakest link of the setup. Do this to make sure
that the signaling is transmitted under all
conditions.
Frame Type Normal/Short Select a corresponding frame type.
Note: When working with S2 Ext ModCod only
Normal frames are possible.
ISI 63 (read only)
This is a default ISI value that in combination with
the GSE label is used to avoid conflicts between
existing ISI's or Labels. (Refer to section:
BBFEncapsulationChannelsonpage232.)
Label 3F:FF:FF (read only)
This is a default label value that in combination
with the ISI is used to avoid conflicts between
existing Labels or ISI's. (Refer to section:
Channelsonpage232.)
CIR Range
0 / 10.000 kbps
Enter a Committed Information Rate for the
in-band signaling messages.
PIR 0 / 400000 kbps Enter a Peak Information Rate for the in-band
signaling messages.
