Physical Description MDM6000 Satellite Modem
8.2 Back Panel Description
The following figure shows the possible connections on the MDM6000. The back panel connections
available depend on the specific hardware configuration of your device.
The maximum force that may be used to fix the SMA (L-Band monitor OUT) connector
is restricted to 1.2Nm!
The maximum force for the other connectors is restricted to 1Nm!
When one of these limits is exceeded, the connectors can be damaged and the
correct functioning of the connectors cannot be guaranteed.
The following figure serves as an example to get an overview on the specifications of
the connectors.
The combination of connectors and modules displayed might deviate from your
particular combination.
Please refer to Appendix-BackPanelCombinationsonpage303 to get an overview on
the possible back panel combinations.
The following back panel applies to a configuration with sales options:
• OU-00 or OU-01 or OU-02 (selectable via license key);
• IU-01;
• RO-01;
• PS-00.
