Feature Descriptions MDM6000 Satellite Modem
14.1.5 Spectrum Polarity
MDM6000 >> Modulator >> Spectrum Polarity
Spectrum inversion can be enabled in case an inverting upconverter is used. As a general rule
transmissions on satellite need to be non-inverted.
Most modern demodulators can detect and automatically adapt the spectrum
inversion.
14.1.6 Output Level
MDM6000 >> Modulator >> Output Level
The output level must be set according to the network requirements.
For L-band the range is between -35/+7 dBm (± 2dB)
For IF-band the range is between -35/+10 dBm (± 2 dB);
The step size is 0.1dB.
