General Device Settings and Actions MDM6000 Satellite Modem
12.14.1 Configure the Terminals
Navigate to the following location.
MDM6000 >> Remote Terminals
The following table shows the available "Terminals" parameters.
» Click Add to add a terminal.
» To delete, select a row and click Delete.
Parameter Value Description
Name Enter a logical terminal name.
For example, the name of the city where the remote
device is located.
Note that spaces are not allowed.
Terminal ID Range
0 - 65277
Enter the identification number of the corresponding
terminal (remote device).
Make sure that the Terminal ID numbers
used are unique!
Note: The Terminal ID of the remote device
can be found under device identification or
control plane on the remote device itself.
Refer to sections:
deviceidentificationonpage107 and
controlplaneonpage124.
Control IP
Address
x.x.x.x The control IP Address is the management IP address of
the corresponding remote device.
When the IP address does not match, the "terminal" will
not be active.
Please refer to the previous figure to get an overview.
Admin State On/Off Activate or deactivate the corresponding terminal.
