Feature Descriptions MDM6000 Satellite Modem
14.1.9 Amplitude Slope Equalizer
MDM6000 >> Modulator >> Ampl Slope Equalizer
Configure the amplitude slope equalizer. An amplitude slope in the up-converter or in the high
power amplifier can be compensated by using this equalizer. The equalizer has a maximum range of
± 2 dB/50 MHz.The compensation can be set in the range between -7 and +7.
The slope equalizer can also be used to compensate for cable slope.
14.1.10 Symbol Rate
MDM6000 >> Modulator >> Symbol Rate
Define the symbol rate in Mbaud.
14.1.11 Stream Mode
MDM6000 >> Modulator >> Stream Mode
Select the appropriate stream mode,
• Single Stream;
• Multi Stream.
14.1.12 Measured Packet Count and Measured Bit Rate
The measured packet count should be incrementing.
The measured Bit Rate should match the bit rate inserted by the source device.
