Feature Descriptions MDM6000 Satellite Modem
14.11.3.3 TS Encapsulation Channels
Parameter Description
Channel Name Enter a logical channel name, for example the service that is transported
over this channel (ACM Signalling, VoIP Traffic, )
Enable This must be Enabled (On) otherwise the channel is not recognized and the
data cannot be encapsulated.
PID Select one of the available PID names.
The available names are defined under TS Encapsulation PIDs.
Label Enter a Label that you want to assign to this channel.
Use a label when you want to address a specific receiver.
For MPE a label is required!
For more information refer to GSEHeaderonpage291.
In a unicast configuration, the channel corresponds with one terminal.
In a "multicast" configuration, a "multicast Label Type" must be specified and
the terminals belonging to the specified "multicast label type group" can
receive the channels.
A receiver has the "multicast Label Type" configured in its filters, in the case
of a hardware receiver and in the decapsulation configuration block in the
case of a software receiver (i.e. NOP1760).
Terminal
Name
When ACM is active, then the terminal name must correspond with the
terminal name of the receiving device. This to make sure that the ACM
signaling is transported to the correct device.
The terminal name of the receiving device is defined under
Root >> Terminals
