Appendix - Technical Specifications MDM6000 Satellite Modem
19.3 Modulation Interfaces
L-BAND
Connector N(F), 50 Ohms
(optional SMA adapter)
Frequency 950 - 2150 MHz (10 Hz steps)
Level -35/+7 dBm (+/- 2dB)
Return loss > 14 dB
Switchable 10MHz Reference
Spurious performance
Better than - 65 dBc/4kHz @ +5 dBm output level and > 256kBaud
Non-signal related: < - 80 dBc @ +5 dBm output
IF-BAND (CONFIGURATION OPTION)
Connector BNC (F) - 75 ohms
(intermateable with 50 ohms)
Frequency 50 - 180 MHz (10 Hz steps)
Level -35/+10 dBm (± 2 dB)
Return loss 50 ohms: > 14 dB
75 ohms: > 20 dB
Spurious performance
Better than - 65 dBc/4kHz @ +5 dBm output level and > 256kBaud
Non-signal related:< - 80 dBc @ +5 dBm output
L-BAND MONITORING
Connector SMA (F), 50 ohms
Frequency Same as L-Band output frequency or
1050 MHz in case of IF output option
only
Level -45 dBm
Return loss > 10 dB
