Feature Descriptions MDM6000 Satellite Modem
14.1.7 Clock Output
MDM6000 >> Modulator >> Clock Output
Enables or disables the transmission of a 10MHz clock signal on the L-BAND output interface.
For the reference clock settings and characteristics, refer to ReferenceClockonpage129.
14.1.8 Carrier Modulation
MDM6000 >> Modulator >> Carrier Modulation
This command controls the carrier modulation:
• On (Operational modulated carrier signal);
• Pure Carrier (unmodulated output signal);
• Test modulation (pulse);
• Test modulation (clock/4);
• Test modulation (clock/8);
• Test modulation (clock/16).
