Appendix - Technical Specifications MDM6000 Satellite Modem
19 Appendix - Technical Specifications
19.1 Input Interfaces
• Auto switching 10/100/1000 Base-T Ethernet interfaces;
• Maximum rates: 380mbit/s bidirectional
(200Mbit/s for imix traffic mix, 75kpps each direction);
• Layer 2 bridge function: ethernet over satellite
(IPv6/VLAN/MPLS compatible);
• Layer 3 static router function: IPv4 packets over satellite;
• Up to 100 routes;
• Advanced QoS features:
Adaptive Traffic Shaping on bitrate or symbolrate according to PIR/CIR
Flexible traffic classification on VLAN/MPLS/IPv4/IPv6;
• GSE, MPE, XPE or ULE Encapsulation/Decapsulation of IP/
Ethernet frames in DVB-S2 & S2 Extensions;
• Data filtering (downlink): Up to 64 receive filters.
19.2 Modulation and Demodulation
SUPPORTED MODULATION SCHEMES AND FEC
• DVB-S2
Outer/Inner FEC: BCH/ LDPC MODCODs
52 MODCODs (short & normal frames):
QPSK from 1/4 to 9/10
8PSK from 3/5 to 9/10
16APSK from 2/3 to 9/10
32APSK from 3/4 to 9/10
