How to Manage the Device MDM6000 Satellite Modem
11.6.7 Example: Set the Input Frequency
» Select Demodulator using the corresponding Soft button;
» Navigate to Input Frequency;
» Click OK;
New value is displayed, indicating the current position by a blinking number.
» Insert the new value using the corresponding Soft Buttons;
» Click OK;
» The new value is displayed on the front panel.
11.6.8 Example: Set the Output Frequency
» Select Modulator using the corresponding Soft Button;
» Navigate to Output Frequency;
» Click OK;
New value is displayed, indicating the current position by a blinking number.
» Insert the new value using the corresponding Soft Buttons;
» Click OK;
» The new value is displayed on the front panel.
11.6.9 Example: Check the Alarms
» Select Alarms using the corresponding Soft Button;
(use the soft button arrows to navigate through the root menu.)
» Navigate to Active Alarms or Memorized Alarms;
» Click OK;
» Navigate through the tree menu to see the active or memorized alarms.
It is possible to clear the Memorized Alarms by pressing the OK button during three
seconds.
