Feature Descriptions MDM6000 Satellite Modem
14.12.4 Monitoring
GSE Decapsulation
Parameter Description
Output Bit Rate Displays the bit rate that is forwarded to the terminal.
Forwarded Bytes Displays the number of bytes that are forwarded to the terminal.
Forwarded Packets Displays the number of packets that are forwarded to the terminal.
Dropped Bytes Displays the number of payload bytes that are dropped before
they were send to the terminal.
Dropped Packets Displays the number of payload packets that are dropped before
they were send to the terminal.
Channels
These monitoring settings display the monitoring settings per channel.
When channels are defined per service or remote site it is easy to monitor the decapsulation per
service. In this case, when bytes/packets are dropped for a particular service this is detected in these
monitoring statistics.
