General Device Settings and Actions MDM6000 Satellite Modem
12.9 Device Monitoring
MDM6000 >> Device Setup >>Monitor
The following device level parameters are monitored.
• Temperature;
• Board Power supply;
• CPU (Central Processor Unit) load;
• Memory usage;
• Uptime.
12.10 Device Redundancy
Redundancy is very important as a single failure of the MDM6000 affects many services at the same
time.
Reliable operation of the MDM6000 in a satellite network is of key importance. The MDM6000 works
seamlessly together with the Newtec USS0202/USS0212 redundancy switches to provide
best-in-class system uptime.
Refer to the user manual of theUSS0202/USS0212 Universal Switching System.
The following figures shows a 1+1 protection scheme built up with the USS0202 switch, one in
normal operation and one in redundant operation.
Normal Operation
